| Input maximum voltage | 10dBm |
|---|---|
| Input maximum current | DC - 2GHz |
| Filter type | Low pass filter |
| Wave guide | Ø14 |
| I/O | SMA |
| Shield Effectiveness | 60dB @ 6G - 40GHz |
Size Information / External appearance▲
| Width | 40mm |
|---|---|
| Length | 110mm |
| Height | 18mm |
| Fixing hole bolt | M4 |
| Applied Panel Thickness | 5mm |
